Trinamic drivers are smooth, efficient and much more configurable. Well designed compact controller loaded with enhancements compared to the units you get with the CNC hardware. Spark concepts reached out to me offering any help that I might need I look forward to working with them in the future. I will be using this with my Long Mill and my second home built machine. I am planning on hooking up this weekend. I'm very impressed with quality and pkging. It is living up to all the documentation no complaints Have yet to finish setting it up, but Mark has been super helpful, excites for what this controller can do! Posted by Preston Landon on 19th Sep 2021 Documentation:įor user guides, hook-up instructions and all other documentation please check out the CNC xPRO V5 Github repository. As such, the xPRO V5 can be used with most current GRBL senders and post-processors. Note: The xPRO V5 runs a 32bit port of the GRBL.

Vetric Vcarve or Aspire depending on design (drawing and CAM, includes GRBL postprocessor) (paid).

XPRO V5 WebUI (or CNCjs for USB mode (free/opensource))įor artwork (think signs, drawings, plaques, awards, etc):.

Fusion 360 (both CAD design and CAM, includes GRBL postprocesser by default) (free for hobbyists).

The xPRO comes fully assembled and programmed so all you need to do is wire up your motors and start cutting! The xPRO V5 is defaulted to support dual Y machines, or XYYZ, machines with motor current of 2.8A.įrom the computer side we have found that CNCjs Desktop is amazing and packed with great features! (open source / free download).įor designing parts here at Spark Concepts we use the following stacks:įor mechanical parts (think gantry plates, mounts, boxes, etc):

Selectable limit switch voltage (5V or 24v).

4 software defined, independent motor drivers can:.

Built-in Heatsink & Temperature Controlled Cooling Fan.

USB-C interface work with GRBL sender programs.

Sleek Web Interface with cut-from-SD capability (SD card included).High Power 6A stepper drivers based on the Trinamic TMC5160.

#Cnc usb controller manual 32 bit#

The xPRO V5 is the most advanced GRBL based motion controller in the World! Our plug and play xPRO V5 brings you the advanced stepping and power of Trianamic drivers along with Wifi and USB interfaces, all powered by a 32 bit processor and wrapped in a beautiful ABS case (with integrated cooling).
